The wire telephones and mobile phones have become the keystone of any workplace or any business. Due to huge dependency on telephonic communication in today’s business, its overall cost plays crucial role. When you make thousands of calls per month, it brings stack of bills on the table.

Aegis Informatics Pvt Ltd., GSM Fixed Wireless Terminal manufacturer India connect your business with GSM world with its compact and intelligent GSM voice XN520 series terminals which satisfies your cost cutting voice communication need and also provide next generation features. such as GSM call recording, conference call, hot dial and plethora of others as illustrated below. Besides this, AIPL the GSM Fixed Cellular Terminal manufacturer offers advanced version of GSM Voice Terminal XN520 TURBO with multiple features.

Aegis XN520 PRO is a GSM Voice Terminal that will connect GSM Sim with two parallel FXS Ports. These ports can be interface with PBX, telephone instrument, dial pad and desktop softphone for making and receiving calls through GSM network in any office.

Aegis XN520PRO GSM Voice Terminal has the utility at many types of organization like in Call center, corporate offices, banks, share brokers Manufacturing units, hotels, residences and other such establishments.

Silent Features

Easy to install- The process for GSM Voice Terminal XN520 PRO installation is quick and trouble free.

User friendly GUI- User friendly GUI- Aegis caters user friendly window base software for GSM Voice Terminal.

Rugged Design– Aegis’s quality assurance procedure of raw material, operational working of hardware and software, production testing and beta testing phase makes it rugged and reliable product.

High gain antenna– Aegis GSM Voice Terminal XN520 PRO offers 3 mtr. wire antenna for high gain

Emergency number- Aegis GSM Voice Terminal XN520 PRO has a provision for a user to dial emergency numbers for services like Police, Fire Brigade or Ambulance without SIM or without network registration. Maximum 4 emergency numbers of 4 digits can be programmed.

Hot dialing- Will direct the call to certain pre-configured number after a few seconds receiver is being lifted or hooked off.

Welcome message- Aegis GSM Voice Terminal XN520 PRO offers plethora of customizable messages, meeting the need of the organization. In the long run, it will become a corner stone in the overall performance of the company. The interactive purposeful greeting at the beginning of the conversation will set a tone for the topic with amiable atmosphere.

Day message
Aegis offers a tailored message facility as per the requirement such as “Thank you for calling my company. Your call important to us. Please hold while we connect your call. It will be recorded due to quality purpose.”

Night message
This works same as that of Day message “Thank you for calling my company. Your call important to us. Our office timing is 9.30 am to 6.00 pm. please leave your message after beep, and we'll respond to you as soon as possible. Thank you and have a nice day”

Call recording- Aegis XN520 PRO GSM Voice Terminal have provision of in-built call recording facility, it allows you to record phone conversations into device SD card automatically. It also allows users to manage all stored recordings and information with its Advance User-Friendly management software.

Voice mail facility-Aegis XN520 PRO Voice Terminal have provision of in-built voice mail facility which automatically plays an after-office hours greeting and give provision to customers to leave their message with contact number detail. You can see customer detail and message in aegis software and reply accordingly. It helps you to win and keep customer.

Unlimited conference- Aegis GSM Voice Terminal XN520 PRO provides multi-party conference facility (up to 8 Parties) on GSM network with quality assured voice quality. For any business organization, call conferencing is powerful tool that saves time and gives real-time connectivity between the employer and employees. Be it a project meeting, team meeting, client meeting, presentation or sales report, call conferencing gives you 24 X 7 collaboration with an ease of configuring remote users.

Speed dial – Aegis XN520PRO GSM Voice Terminal offers speed dial facility for a hundred numbers vary from 0 to 99. It allows user to establish a call by just pressing a single key. The user can update these short keys by management software provided along with this model.

Technical Specifications

Air interface standard: GSM850/1900Mhz,900/1,800Mhz phase 2+ full band

Frequency ranges:
GSM 850: Transmission: 869.2 ~ 893.8MHz, Reception: 824.2 ~ 848.2MHz
GSM 1900: Transmission: 1, 930 ~ 1, 990MHz, Reception: 1, 850 ~ 1, 910MHz
GSM 900: Transmission: 890 ~ 915MHz, Reception: 935 ~ 960MHz
GSM 1800: Transmission: 1, 710 ~ 1, 785MHz, Reception: 1, 805 ~ 1, 880MHz

Phone interface: supply RJ-11 Phone Interface

Desktop connectivity: USB Port

SD card: 16GB

Recording in 16GB: 35000 Minutes

Hanging voltage: 45V

Picking off voltage: 30mA / 41mA

Dialing tone Frequency: 450Hz

Antenna interface: Antenna amplifying>3db

Sensitivity: <- 104DBM

Transmitting power <3W

AC-Adapter interface: Input: AC 110~240VAC 50~60Hz Output: 12DC 1A

Operation Circumstance:
Operation temperature: -10c~60C
Storage temperature:-20C~70C
Operation humidity: 45%-95%
Atmosphere pressure:86-106Kpa
Environment noise: <- 104dbm
Antenna Amplifying: >2.5db
Dialing frequency: 450Hz
Hanging voltage: 45V
Picking current: 30mA/41mA
